BULLS-5000A MTP/MPO POLISHING MACHINE
Bulls-5000A is widely used for polishing multi-core MT ferrules in mass production, it can also polish single core fiber optic connector products, other fiber optical products like photonic components, medical fiber optic, fiber optic sensor, etc. All rotating structure are bearings and patented, which ensures the high precision & durability of the machine. Good process scalability, can provide stable machine platform support for special 3D index requirement. Pressure, time and speed be set by program, all are with real time feedback and added the pressure calibration function, which can correct the equipment pressure. Easy operation, no maintenance.
Classification:
Polishing machines
Key words:
Features:
· Operation of touch screen to storage or calling polishing program, each of the parameter can be lock or unlock according to requirement which can ensure it will not be changed randomly.
· Pressure, time and speed be set by program, All are with real-time feedback.
· Support slow start speed and slow add pressure to ensure the maximum process flexibility and best product quality , reduce or avoid crack of optical fiber in the polishing.
· Pressure is stable and precision, Closed-loop program control for the pressure and speed.
· The structure is optimized to keep stability and accuracy of long time use, can be realized polishing 24 MT ferrule in one time,(Bulls patent structure),the efficiency of polishing is increased great(close to 70-100%)，the cost of consumable reduce obviously (close to 70-100%).
· Can support Both Chinese and English operation interface.
| Overall Dimension: | 520mmx395mmx405mm |
| Voltage: | 100-240VAC,2AFuse |
| Power: | 60w |
| Air Source: | 6 bar<=p<=9 bar， Recommended pre-filter accuracy:3um |
| Velocity range: | 30-180rpm（The highest speed: 200rpm）Suggestion 30-165 |
| Rpm Slow start range: | 0-60’s |
| Pressure range: | 0-9800g(The equivalent of about 0-22 LBS ) |
| Slow start range: | 0-60’s |
| Time range: | 0-900 ’s |
| Program capacity: | 15 kinds |
| Each program allows: | 5 steps |
